OVERHEAD BINS


WELKER OVERHEAD BINS
24 TON SINGLE COMPARTMENT BIN -------   $8,212.00
24 TON DOUBLE COMPARTMENT BIN ------   $10,285.00
24 TON BIN IS 1250 CUBIC FEET OR HOLDS 924 BUSHEL
8 ft. DRIVE THROUGH CLEARANCE
28 TON SINGLE COMPARTMENT BIN  ------   $9,355.00
28 TON DOUBLE COMPARTMENT BIN ------  $11,393.00
28 TON BIN IS 1390 CUBIC FEET OR HOLDS 1044 BUSHEL
 9 ft DRIVE THROUGH CLEARANCE
30 TON SINGLE COMPARTMENT BIN  ------   $9,780.00
30 TON DOUBLE COMPARTMENT BIN  ------  $11823.00
30 TON BIN IS 1540 CUBIC FEET OR HOLDS 1235 BUSHEL
8 ft. DRIVE THROUGH CLEARANCE

OTHER SIZE BINS AND ADDED HEIGHTS AVAILABLE
ADDITIONAL PRICE FOR ADDED HEIGHT :
1 ft  ------  $194.00
2 ft  ------  $962.00
3 ft  ------ $1490.00

COMMON QUESTIONS & ANSWERS
What does an empty bin weigh?   A standard bin weighs less than 3 tons.
What are my color options on a Bin?   White is our standard color.
Does a bin need to be secured?   Yes, a bin needs to be secured!
How do you do that? You will need four -2ft pieces of 5/16 or 3/8 chain to secure a bin to the concrete. The chains may be placed in the concrete as it is poured, preferably attached to an anchor (rebar) in the concrete.  Leave 6 inches of each chain tail protruding from the concrete 5-6 inches apart.  These 6 inch pieces will then be used to secure the bin runner (4x4 square tube).  The two ends of each chain are then lapped over the runner and secured with a bolt.
Can we haul a Bin ourselves? Yes, or we can arrange a truck to haul it for you.  You will need at least a 24 ft trailer, two- 20ft chains & two binders.
Do I need a permit to haul a Bin? Yes, a $15.00 permit from Nebraska Dept. of Roads.
What do I need to unload & erect a Bin?  We suggest two 4 wheel drive loader tractors.  Our truck drivers will help you unload and get your Bin standing up or we can give you instructions if you haul it yourself.
How tall are the Bins?  A 24 ton Bin is 21 ft to top, a 28 ton Bin is 23 ft to top of bin, a 30 ton bin is 23 ft to top of Bin.
